Wireguard Go
FIPS 140-3 Wireguard-Go Implementation with CryptoComply Go
Deploy WireGuard-style VPN connectivity in regulated environments using a validated cryptographic software foundation and a repeatable build-and-evidence workflow.
Developer Summary:
Wireguard-Go (userspace) patched to use approved algorithms and built on a FIPS 140-3 validated cryptographic software foundation (CryptoComply Go).
Replace non-approved algorithms (ChaCha20-Poly1305, Curve25519, BLAKE2s) with approved equivalents (AES-GCM, P-256, SHA-256 family) and rebuild against CryptoComply Go.
Confirm the FIPS build version (wireguard-go –version) and run the included tests; optionally, verify that cryptographic operations route through the FIPS provider in the test harness logs, so teams have a practical path to deployment with a clearer compliance story.
Build artifacts, patch/integration guidance, and evidence materials (validation artifacts + build provenance + configuration guidance).
Not interoperable with standard WireGuard peers —FIPS-enabled endpoints must pair with FIPS-enabled endpoints.
WireGuard-Go Installation How-To
Quickstart: Build Wireguard-Go FIPS
with CryptoComply Go
This workflow patches wireguard-go to replace non-approved algorithms and builds it on a validated cryptographic software foundation (CryptoComply Go).
Compatibility Notes
The cryptographic suite and Noise construction string are updated; FIPS-enabled peers must connect to other FIPS-enabled peers.
This use case is based on wireguard-go (userspace), not the kernel module; that changes how you deploy and test.
Non-approved algorithms are replaced with approved alternatives (e.g., AES-GCM, P-256, SHA-256 Family building blocks), and the build is aligned with CryptoComply Go.
Most teams do a parallel rollout: deploy FIPS peers and migrate tunnels in phases.
Build from Source
1) Clone the wireguard-go source
git clone https://github.com/WireGuard/wireguard-go.git
2) Apply the SafeLogic patch
cd wireguard-go git apply <path>/sl-wireguard-go-fips-modification.patch
3) Run tests
cd device go test
4) Build and install
cd .. make make install
5) Verify installation
wireguard-go --version
Expected output example:
wireguard-go v0.0.20250522-sl-fipsU serspace WireGuard daemon for linux-arm64.I nformation available at https://www.wireguard.com. Copyright (C) Jason A. Donenfeld
Getting Started with Docker
Prerequisites
- Add CryptoComply Go to the
cryptocomplydirectory - Add CryptoComply Core to the
cryptocomplydirectory - Add the Go package to the
cryptocomplydirectory
Build
docker build -t wg-fips .
Run
docker run -it wg-fips
Run example apps
docker build -t wg-fips -f dockerfile.demo . cd example docker compose up --build
Run tests
docker build -t wg-fips -f dockerfile.demo . cd example docker compose -f docker-compose.test.yaml run wg-server docker compose -f docker-compose.test.yaml run wg-client
Advanced Verification
If you use the test harness with debugger logs, you can inspect evidence that cryptographic operations are executed via the FIPS provider shared object.
cd gdb-logs cat fips-breakpoints.log
Example snippet:
Breakpoint ... ecdh_derive; #0 ... in ecdh_derive () from /usr/local/lib/ossl-modules/fips.so
Want the Patch + Automated
Build Package?
SafeLogic provides the Wireguard-go FIPS patch and a portal-delivered use case package (including Docker examples and a test harness) to automate these steps and accelerate validation in your environment.
FIPS Cryptography Changes (WireGuard-Go)
A summary of the changes in the cryptographic suite and build approach.
Component / Primitive
Default in WireGuard-go
SafeLogic-Approved Approach
Notes
Scope
Kernel WireGuard (kernel-space)
wireguard-go (userspace)
Userspace build is patched/rebuilt; deployment differs from kernel module
Transport AEAD
ChaCha20-Poly1305
AES-GCM
Uses a FIPS-approved AEAD; affects peer compatibility
Key Exchange (ECDH)
Curve25519 (X25519
NIST P-256
Uses an approved NIST curve
Handshake hash/KDF building blocks
BLAKE2s
SHA-256 / HMAC / HKDF (SHA-256)
SHA-256-family building blocks
Noise construction identifier
Standard WireGuard Noise string
Updated Noise string
Prevents standard peer interoperability
Cryptographic foundation (Go)
Standard Go cryptography paths
CryptoComply Go (validated)
Rebuilt on a validated cryptographic software foundation for Go.
The Compliance Gap with
Standard WireGuard
Standard WireGuard uses a cryptography suite chosen for simplicity and performance. That’s a great fit for many environments, but it creates friction when buyers require FIPS 140-3-validated cryptography and evidence that cryptographic operations are implemented through validated modules and approved algorithms.
How SafeLogic closes the gap: SafeLogic provides a practical path to run userspace wireguard-go in regulated environments by patching wireguard-go to replace non-approved algorithms with approved equivalents and rebuilding it on a FIPS 140-3 validated cryptographic software foundation (CryptoComply Go). SafeLogic also provides verification steps and the artifacts teams typically retain for audits—validation artifacts (as applicable), build provenance, and configuration guidance—so compliance is implementable and auditable rather than assumed.
Access, Rollout, and Evidence
A clear path from artifacts to production, including rollout steps and the evidence most compliance programs expect.
How Customers Access it
Customers access the required build artifacts through SafeLogic’s Customer Portal and integrate them into internal artifact repositories and CI/CD pipelines.
Delivery Formats
Pre-built artifacts and/or build toolchain integration (based on customer workflow)
Supported language
Go (wireguard-go userspace implementation)
Supported platforms (OS/architectures)
CryptoComply builds are available across a broad set of operating systems and CPU architectures, with support spanning rigorously tested environments.
Selecting the right build
Customers use the Customer Portal to locate the exact build by product, version, operating system, architecture, and language, then pull artifacts into internal repositories and pipelines.
Need the exact OS/architecture matrix for your environment?
Typical Rollout
Proof of Concept
Confirm environment fit and peer model.
Integration
Rebuild WireGuard-go against CryptoComply Go and validate configuration.
Verification
Confirm approved algorithm paths and prepare evidence package.
Production
Deploy through standard rollout and monitoring.
Evidence for Auditors
- Module Security Policy / validation artifacts for the underlying cryptographic foundation
- Guidance on approved configuration/operation (program-dependent)
- Integration notes mapping implementation behavior to the validated foundation
Frequently Asked Questions
Is this interoperable with standard WireGuard?
Not by default. The cryptographic suite changes and the Noise construction string is updated, so standard WireGuard peers won’t interoperate. FIPS-enabled endpoints must pair with FIPS-enabled endpoints.
Which algorithms change in the FIPS-enabled suite?
The suite moves to approved alternatives (for example, AES-GCM, NIST P-256, and SHA-256-family building blocks such as HMAC/HKDF).
What changes operationally?
It remains a userspace VPN deployment (WireGuard-go), but you adopt the SafeLogic build, rebuild against a validated cryptographic foundation, and plan peer compatibility during rollout.
Does this meet FIPS 140-3 requirements?
It’s built on validated cryptography and uses approved primitives. Whether this satisfies your program depends on your definition of “meets FIPS” and the evidence your auditors expect (e.g., operational environment, boundary considerations, and documentation).
Does this affect performance?
Performance varies by platform and traffic profile. In many enterprise environments, AES-GCM benefits from hardware acceleration on modern CPUs, and benchmarking during POC is the best way to confirm expected performance for your deployment.
What artifacts do we get for auditors?
Typically: module Security Policy / validation artifacts for the underlying cryptographic foundation, plus integration and configuration guidance aligned to your program needs.
Do we need kernel WireGuard support?
No. This use case is based on WireGuard-go (userspace).
How do we verify we’re using approved cryptographic paths?
Verification typically comes from build provenance (validated foundation), configuration guidance, and verification steps aligned to your compliance program.
Is this based on Go “BoringCrypto”?
This use case is built on CryptoComply Go as the validated cryptographic foundation. If your program specifically references Go+BoringCrypto or another mechanism, SafeLogic can help map your requirements to an approved deployment approach.
